| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | RVYUAN |
| 인증: | ISO9001/ISO14001 /UL/SGS |
| 모델 번호: | USTC |
| 최소 주문 수량: | 20kg |
| 가격: | 협상 가능 |
| 포장 세부 사항: | 판지를 가진 스풀 |
| 배달 시간: | 근무일 기준 15일 |
| 지불 조건: | T/T/페이팔 |
| 공급 능력: | 귀하의 요구를 충족 |
| 지름: | 0.071mm | 온도: | 155 |
|---|---|---|---|
| 인증: | IEC/NEMA/JIS/RoHS/ISO | 지휘자: | 구리 |
| 가닥: | 6500 | 항복 전압: | 최소9500 |
| 표지 소재: | 줄자 | 키워드: | 솔리드 6500 가닥 Kapton 테이프 리츠 와이어 에나멜 구리 와이어 산업용 고주파 애플리케이션 HUAYE TECH |
| 강조하다: | 6500 strands kapton taped litz wire,enameled copper wire high frequency,industrial litz wire with warranty |
||
This industrial-grade flat taped litz wire is engineered for high-frequency applications, featuring 6500 strands of enameled copper wire with Kapton tape insulation. Manufactured by HUAYE TECH, it delivers superior performance in demanding electrical environments.
| Parameter | Technical Requirement | Sample 1 Measurement |
|---|---|---|
| Single Wire Diameter (mm) | 0.075-0.084 | 0.076-0.078 |
| Conductor Diameter (mm) | 0.071±0.003 | 0.068-0.069 |
| Width (mm) | 7.4±0.3 | 9.38-7.54 |
| Thickness (mm) | 7.4±0 | 9.38-7.54 |
| Resistance (Ω/m) | ≤0.000814 | 0.000705 |
| Breakdown Voltage (V) | ≥9500 | 11400 |
| Pitch | 130±200 | √ |
The combination of high strand count, precision flat geometry, and high-voltage-rated Kapton tape insulation provides engineers with a reliable, ready-to-use solution that simplifies winding processes, improves thermal management, and ensures long-term durability under extreme electrical and thermal stress.
Whether designing for next-generation power grids or rugged industrial environments, this flat taped litz wire delivers the performance and safety margins your applications demand.
